MS / SS 304 / SS 316 PTFE / FEP / PFA LINED INSTRUMENT TEE

Galaxy Thermoplast Pvt. Ltd. has been devoted to foster innovation in plastic production with a high degree of accuracy and quality. Being in this business for the past 17 years, we have in-depth knowledge about various thermoplastics and have emerged as the precision manufacturer of Instrument Tees in FEP and PFA thermoplastics. SS 304 PFA Lined Instrument Tees, both, have a tensile strength of 3,400 and 3,600 respectively, thus having strong mechanical properties and dielectric conductivity. Thereby, instrument tees are fundamental to purified water distribution systems they allow assembly of pressure gauges avoiding any dead-legs i.e. the stagnant, contaminated water accumulated between the valve and the water distribution circle.

Manufacturer of Comprehensive Range PTFE Line Instrument Tee, Perfluoroalkoxy Lined Instrument Tee, SS 304 PTFE Lined Instrument Tee, PFA Lined Tees, PTFE Lined Instrument Tees, Instrument Tee Fitting, High Quality PTFE Lined Tees, SS 304 PTFE Lined Tees Supplier in Mumbai, India.



Instrument Tee Dimensions, Dealer & Distributor of PFA Lined Tee, Largest Stockist of FEP Lined Piping Instrument Tees, PTFE Lined Stainless Steel Instrument Tees, Polypropylene Lined Instrument Tees, PTFE Lined Instrument Tee Manufacturer, PTFE Lined Instrument Tee Price, MS Lined Pipe Fittings Instrument Tee in India.

We are stockists and suppliers of MS FEP Lined Instrument Tees are soft and fabrication-friendly, being the most chemically inert of most thermoplastics tees. They are transparent and promote good visual clarity. As exporters of SS 316 PFA Lined Instrument Tees, we supply cleanable and drainable tees with enhanced surfaces finish to the pharmaceutical industry. Non-solvency similar to FEP, these PTFE Lined Instrument Tees are dormant to most chemical except molten alkali metals and gaseous fluorine.

PTFE Lined Instrument Tee Specification

Size : 25 NB to 300 NB

Outer body : ASTM A 395 Gr 60-40-18

Flange Connection : ANSI B 16.5

Face to Face : ANSI B 16.10

Spark Test : 15 KVA

Hydro Test : at 29.8 kg/cm2

FEP- Max Temp : 180° C

PP Max Temp : 100° C

PFA Max Temp : 200° C


Dimensional Standards of Polytetrafluoroethylene Lined Instrument Tees


SS 304 Lined Instrument Tee Dimensions
B - 1
NB - 2
INSTRUMENT TEE
C
C - 1
15
120
50
25
25
120
50

15
135
50
40
25
135
50
40
135
75

15
150
50
50
25
150
50
40
150
75

15
180
50
80
25
180
50
40
180
75

15
200
50
100
25
200
50
40
200
75

15
250
50
150
25
250
50
40
250
75

15
275
50
200
25
275
50
40
275
75

15
325
50
250
25
325
50
40
325
75

15
355
50
300
25
355
50
40
355
75

Dimensional Standards Of Fluorinated Ethylene Propylene Lined Instrument Tee :

All dimensions are in mm otherwise specified & as per ANSI B1 6.9.


Material of Construction :

A) Tee & Cross are supplied either in FEP OR PFA lined depending on process liquid handled & as per standard resin specification. ASTM D 2116 & ASTM D 3307 Type II respectively.
B) ASTM-A-234, Grade WPB in compliance with ANSI-B-16.28.
C) Tee & Cross are being supplied with fixed flanges. However it can be supplied with loose flanges as per individual customer's requirement & confirm to ASTM A-105 or IS- 2062.
D) GTPL offers SS fittings as per individual customer's requirement.


PTFE Line Instrument Tees Ready Stock Available for Various Application Industry

We offer a wide range of MS PTFE Lined Tees through a worldwide network of stock-keeping branches. These MS PTFE Lined Instrument Tee is use in various industries like :

•  SS 304 PTFE Lined Instrument Tee uses in Chemical Industry

•  PTFE Lined Instrument Tees uses in Power Generation Plants

•  PFA Lined Tees uses in Oil & Gas Industry

•  MS PTFE Lined Pipe Tees uses in Petrochemical Refining Industry

•  MS FEP Lined Instrument Tee uses in Paper & Pulp Industry

•  MS PFA Lined Instrument Tee uses in Pharma Industry

PTFE Lined Instrument Tee used in Application Industry
