MS / SS 304 / SS 316 PTFE / FEP / PFA LINED FLUSH BOTTOM VALVE

Galaxy Thermoplast Pvt. Ltd. uses state of the art techniques for production as a manufacturer and supplier of products like PFA Lined Flush Bottom Valves. Their high-end knowledge about the modern fabrication and lining techniques allows them to give customers the products that suit their needs and requirements. SS 304 PFA Lined Flush Bottom Valves are also known as Bottom Valves or Drain Valves. It is widely used to flush out the liquid or the slurry from the bottom of reactors, receivers and huge tanks. SS 316 FEP Lined Flush Bottom Valves assure perfect drainage of the liquid or slurry from the bottom of the tank.

Manufacturer of Comprehensive Range PTFE Line Flush Bottom Valve, Flush Bottom Valve, Perfluoroalkoxy Lined Flush Bottom Valves, SS 304 PTFE Lined Flush Bottom Valve, PFA Lined Flush Bottom Valves, SS 316 PTFE Lined Flush Bottom Valve, High Quality PTFE Lined Flush Bottom Valve Supplier in Mumbai, India.



PTFE Lined Flush Bottom Valves Manufacturer, PTFE Lined Flush Bottom Valve Price, Largest Stockist of FEP Lined Flush Bottom Tank Valve, PTFE Lined Stainless Steel Flush Bottom Valve, Teflon PFA Lined Flush Bottom Valve, Dealer & Distributor of PFA Lined Flush Bottom Valves, MS Lined Flush Bottom Valve in India.

The unique design of the MS FEP Lined Flush Bottom Valve prevents the formation of the dead area in the valve. This ensures no holdup area in the tank or the vessel. MS PFA Lined Flush Bottom Valves are generally found on ships, chlorine manufacturers, etc. PFA/FEP Lined Flush Bottom Valves have low purchase cost and low maintenance cost too. The variety of PFA/FEP Lined Flush Bottom Valves provided by Galaxy Thermoplast Pvt. Ltd. has satisfied the customer’s requirements. Thus they are well renowned in the national and international markets, making their way to the top.

PTFE Lined Flush Bottom Valve Specification

Size : 20 NB to 200 NB

Standard Resin Specifications : PTFE : ASTM D 1457, PFA : ASTM D 3307, PVDF: ASTM D 3222, FEP : ASTM D 2116

Outer body : ASTM A216 ECB/VF8/CF8M + PFA/FEP

Design Standard : BS-5351, BS 5146

Face to Face : ANSI B 16.5; 150#

Spark Test : 15 KVA

Hydro Test : at 29.8 kg/cm2

Test Standard : API 598

PFA Max Temp : 200° C


Dimensional Standards of Polytetrafluoroethylene Lined Flush Bottom Valve


SS 304 Lined Flush Bottom Valve Dimensions
SIZE
A
B
C
E
E
50 X 25
90
40
100
220
150
80 X 50
127
70
160
430
200
100 X 80
160
88
220
500
200
150 X 100
210
140
330
600
250

Dimensional Standards Of Fluorinated Ethylene Propylene Lined Flush Bottom Valve :

End flanges are drilled to individual specification like BS, ASA, DIN, or JIS.


Material of Construction :
NO.
PART NAME
MATERIAL
1
Valve Seat
PTFE / GFT. D1457
2
Spindle
MS with lining FEP : D-2116, Type -III PFA : D - 3307 Type II
3
Body
Cast Iron, SS-ASTM-A-351 CF8 or CF8M with linin FEP : D-2116, Type-III PFA : D-3307 Type-II
4
Gland
Virgin PTFE, D-1457
5
Bannet
Cast Carbon Steel or Cast Iron
6
Fasteners
SS-304
7
Adopter
MS or SS-304
8
Hand Wheel
Cast Iron or Cast Steel
9
Wheel Nut
MS.

PTFE Line Flush Bottom Valve Ready Stock Available for Various Application Industry

We offer a wide range of MS PTFE Lined Flush Bottom Valve through a worldwide network of stock-keeping branches. These MS PTFE Lined Wafer Type Flush Bottom Valve is use in various industries like :

•  SS 304 PTFE Lined Flush Bottom Valves uses in Chemical Industry

•  PTFE Lined Flush Bottom Valves uses in Power Generation Plants

•  PFA Lined Flush Bottom Valves uses in Oil & Gas Industry

•  SS 316 PTFE Lined Flush Bottom Valves uses in Petrochemical Refining Industry

•  MS FEP Lined Flush Bottom Valve uses in Paper & Pulp Industry

•  MS PFA Lined Flush Bottom Tank Valve uses in Pharma Industry

PTFE Lined Flush Bottom Valve used in Application Industry
