MS / SS 304 / SS 316 PTFE / FEP / PFA LINED ECCENTRIC REDUCER

Galaxy Thermoplast Pvt. Ltd exports and stocks PTFE Lined Eccentric Reducer fittings from its facility in Gujarat. The MS PFA Lined Eccentric Reducer range uses mild steel bodies encapsulated in PFA sheeting, built for pipelines carrying corrosive fluids at specified flow rates. Grades range from carbon steel bodies to SS 316 PFA Lined Reducer and SS 304 PTFE-lined eccentric reducer configurations, each lined to keep the metal body out of contact with process media. Lining thickness spans 3mm to 6mm depending on nominal bore, and reducers go out as concentric or eccentric depending on the pipeline layout.

SS 304 PTFE Lined Eccentric Reducers and SS 316 PFA Lined Reducer Manufacturer in India

---

Leading Supplier of SS 316 PFA Lined Reducer and SS 304 PTFE Lined Eccentric Reducers for Industrial Use

Eccentric reducers keep one side of the bore flat, useful on horizontal lines where trapped air or sediment needs a clear path toward drain valves. These fittings go into chemical processing units, fertiliser plants, pharmaceutical batch reactors and effluent treatment lines. SS 316 PFA Lined Reducer fittings are suitable for chloride-rich service environments, including selected coastal process applications and seawater cooling systems. SS 304 PTFE Lined Eccentric Reduce units are used in selected food and pharmaceutical piping applications, where the chemically inert PTFE lining helps minimise contact between the process medium and metallic substrate. The PTFE lining process page covers how the fluoropolymer bonds to the metal substrate, and the flanged pipe fittings range lists matching gaskets and bolting for these reducers.

MS SS 304 PFA Lined Eccentric Reducers ensures the free flow of liquids for horizontal and vertical lines equally. MS FEP Lined Eccentric Reducers have uses in nuclear, electronic, petrochemical and power plants where vibration, high pressure, impulse and temperature is immensely produced. PTFE/FEP/PFA Lined Eccentric Reducers are offered by Galaxy Thermoplast Pvt. Ltd. at competitive prices and premium quality to its customers. These eccentric reducers are approved by national and international standards.

The lining resin complies with ASTM D1457 Type II for PTFE and ASTM D3307 for PFA, with the base pipe manufactured to ASTM A106 Grade B. Flanges are as per ASTM A105 or IS 2062 Ductile Iron Variants as per ASTM A536 Grade 60-40-18. The tensile strength of the PTFE layer is of the order of 20 - 25 MPa. The lining is designed for continuous service from -200°C to 260°C depending upon operating pressure, concentration of chemicals and service conditions. The lining provides resistance to acids, alkalis, and specified solvents, with chemical compatibility dependent on concentration and operating temperature.

PTFE Lined Eccentric Reducers Specification

Size : 25 NB to 300 NB

Outer body : ASTM A 395 Gr 60-40-18

Flange Connection : ANSI B 16.5

Face to Face : ANSI B 16.10

Spark Test : 15 KVA

Hydro Test : at 29.8 kg/cm2

FEP- Max Temp : 180° C

PP Max Temp : 100° C

PFA Max Temp : 200° C

Dimensional Standards of Polytetrafluoroethylene Lined Eccentric Reducer

NB-1	NB-2	L
20	15	114
25	15	114
25	20	114
40	25	114
50	25	127
50	40	127
80	25	152
80	40	152
80	50	152
100	25	178
100	40	178
100	50	178
100	80	178

NB-1	NB-2	L
150	25	229
150	40	229
150	50	229
150	80	229
150	100	229
200	80	279
200	100	279
200	150	279
250	100	305
250	150	305
250	200	305
300	150	356
300	200	356
350	300	406

Dimensional Standards Of Fluorinated Ethylene Propylene Lined Eccentric Reducers :

Dimensions follow the applicable dimensional standard, with DIN, JIS, or BS flange drilling available according to the specified project requirements. Sizes cover 15 mm (1/2") through 300 mm (12") nominal bore, with reducing ratios set against the line schedule submitted by the client. A fixed flange is the standard supply condition, though loose flanges go out on request for sites that need rotational alignment during erection. The surface finish on the PTFE layer stays under 0.5 micron Ra, which limits scaling in slurry and particulate service. MS PFA Lined Eccentric Reducer stock covers Schedule 40 and Schedule 80 wall thicknesses, with custom lining thickness that can be supplied against an approved drawing. Pre-dispatch testing includes spark testing at 15 kV to check lining integrity, along with hydrostatic pressure testing according to the applicable pressure and flange requirements.

Material of Construction :

A) Reducers & Reducing flanges are from PTFE & as per Standard resin spec. ASTM D 1457 TYPE II & ASTM D-4894 & 5 type-II.
B) Fabricated from Seamless Carbon Steel Pipe as per ASTM-A-106 Gr, B & Flanges confirms to ASTM A-105 OR IS 2062 OR Ductile Cast Iron confirms to ASTM A-395 or SG Iron confirms to ASTM A-536 (60-40-18).
C) Reducers are being supplied with fixed flanges. However it can be Supplied with loose Flanges as per individual customer's requirement.
D) GTPL offers SS fittings as per individual customer's requirement.

PTFE Line Eccentric Reducers Ready Stock Available for Various Application Industry

We offer a wide range of MS PTFE Lined Eccentric Reducer through a worldwide network of stock-keeping branches. These MS PTFE Lined Eccentric Reducers is use in various industries like :
