An eye for detail and a constant effort to fulfill customer needs is what makes us, Galaxy Thermoplast Pvt. Ltd., a successful manufacturer of a line-up of thermoplastic products, like PTFE, FEP, PFA, etc. with each thermoplastic having its speciality, leading to a qualitative solution to your industry requirements. PTFE Lined 45° Elbow is a pipe fitting made from Mild Steel, a kind of Carbon steel, low in Carbon content, lending it more ductility and weldability than other types of steels. MS PTFE Lined 45 Degree Elbows are rust resistant elbows that are used as add-ons as well as fittings to connect pipes at public water supply facilities.

PTFE Lined 45 Deg. Elbows, Manufacturer of Comprehensive Range PTFE Line Elbow, SS 304 PTFE Lined 45° Elbow, SS 304 PTFE Lined 45 Deg. Elbow, PFA Lined Elbow, Lined Elbows, Perfluoroalkoxy Lined Elbow, High Quality PTFE Lined 45 Degree Elbow Supplier in Mumbai, India.

Dealer & Distributor of PFA Lined 45 Degree Elbow, PTFE Lined 45° Elbows Manufacturer, Largest Stockist of FEP Lined Piping Elbows, PTFE Lined Stainless Steel 45 Deg. Elbow, PTFE Lined 45 Deg. Elbow Price, Polypropylene Lined 45 Degree Elbow, MS Lined Pipe Fittings in India.

We are suppliers and dealers of SS 316 FEP Lined 45° Elbows made from Fluorinated Ethylene Propylene, a thermoplastic which is designed to use even at higher temperatures, with their 45° angles channelling a perfect 45° change in the direction of the flowing fluid. As exporters and distributors of SS 304 PFA Lined 45° Elbows, we furnish only quality tested and certified elbows to businesses and industries worldwide.

PTFE Lined 45 Degree Elbow Specification

Size : 25 NB to 300 NB

Flanges Used : ASTM A 105/IS 2062/SS 304/SS 316

Hydro Test : at 29.8 Kg/cm2

Spark Test : 15 KVA

Outer body : ASTM A 234 Gr WPB SCH-40/SS 304/SS 316

Lining : PFA

Dimensional Standards of Polytetrafluoroethylene Lined 45 Degree Elbow

SS 304 Lined 45 Degree Elbow Dimensions
No.Of Holes x Dia Of Holes
Lining Thickness Standard
Lining Thickness Full Vacuum
Length Max.
15 10.80 34.90 88.9 60.3 4x15.9 3.0 3.1 3000
20 16.00 42.70 98.4 69.8 4X15.9 3.0 3.1 3000
25 20.15 50.80 108.0 79.4 4X15.9 3.2 3.5 3000
40 33.90 73.00 127.0 98.4 4X15.9 3.2 3.5 3000
50 45.50 92.10 152.4 120.7 4X19 3.5 4.6 3000
65 55.68 104.80 177.8 139.7 4x19 3.5 4.8 3000
80 70.90 127.00 190.5 152.4 4X19 3.5 5.0 3000
100 94.30 157.20 228.6 190.5 8X19 4.0 5.8 3000
150 114.10 215.90 279.5 241.3 8X22.2 5.0 6.8 3000
200 195.10 269.90 342.9 298.5 8X22.2 5.0 7.9 2000
250 247.40 323.90 406.4 362.0 12X25.4 5.0 8.8 2000
300 297.00 381.00 482.6 431.8 12X25.4 5.0 9.0 ****

Dimensional Standards Of Fluorinated Ethylene Propylene Lined 45 Degree Elbow :

A) All dimensions are in mm otherwise specified.
B) Pipes confirms to ANSI B-36.10
C) Elbows confirms to ANSI B-16.9
D) Flange dimensions are as per ANSI B-16.5 # 150. However other standards Like DIN, JIS, BS can be supplied as per individual customer’s requirement.
E) *** Contact GTPL for Length & type of liner material.
F) Liner thickness on raised face will be 20% lower than specified above

Material of Construction :

A) Pipes & Elbows liner up to 150 NB is from PTFE White liner confirms to standard resin Specification ASTM D-1457, ASTM D-4994 & 95 Type II. Pipes & Elbows of size 200 & above will be supplied either in FEP or PFA or PTFE depending on process liquid handled & as per standard resin specification. ASTM D-2116 & D-3307 Type III & Type II & ASTM D-1457, ASTM D-4994 & 95 respectively.
B) Pipes : Seamless Carbon Steel Pipe as per ASTM-A-106 Gr, B Sch 40.
C) Elbows : Ductile Cast Iron confirms to ASTM A-395 or S.G.Iron confirms to ASTM A-536 (60-40-18)
D) Flanges confirms to ASTM A 105 Gr. B or IS 2062. MS PTFE Lined Pipes are being supplied with one loose & other fixed flange & Elbow with fixed flanges. However it can be supplied as per individual customer's requirement .
E) A Pair of vent holes are provided in each pipe & Elbow.
F) Pipes & Elbow can be supplied in SS as per individual customer's requirement.

PTFE Line 45° Elbows Ready Stock Available for Various Application Industry

We offer a wide range of MS PTFE Lined 45 Degree Elbow through a worldwide network of stock-keeping branches. These MS PTFE Lined 45 Degree Elbow is use in various industries like :

•  SS 304 PTFE Lined 45° Elbows uses in Chemical Industry

•  PTFE Lined 45 Degree Elbow uses in Power Generation Plants

•  PFA Lined Elbow uses in Oil & Gas Industry

•  MS PTFE Lined 45° Elbow uses in Petrochemical Refining Industry

•  MS FEP Lined 45 Degree Elbow uses in Paper & Pulp Industry

•  MS PFA Lined 45 Degree Elbow uses in Pharma Industry

PTFE Lined 45 Degree Elbow used in Application Industry

Leading Manufacturers Of PTFE / FEP / PFA Lined 45 Degree Elbow Other Products
» MS PTFE Lined 45° Elbows Suppliers
» MS Lined Elbow
» MS Lined 45 Deg. Elbow Dealer
» SS 304 PTFE Lined 45 Degree Elbow Distributor
» PTFE Lined 45 Degree Elbows
» PTFE Lined 45 Degree Elbow Price
» PTFE Lined 45 Deg Elbow Manufacturer
» PTFE Lined Stainless Steel 45 Degree Elbow
» Polypropylene Lined Elbows Traders
» PFA Lined 45 Degree Elbow Manufacturer
» FEP Lined 45 Degree Elbow
» Lined 45 Degree Elbow Definition
» 45° Elbows PTFE Lined
» SS 304 Lined 45 Deg Elbow Exporter
» SS 316 Lined 45 Degree Elbow Stockist
» PTFE Pipe Fittings Wholesaler
» PTFE Lined 45 Deg. Elbows Stockholder
» PTFE & PFA Lined Piping Elbows Dimensions
