CS / MS / Stainless Steel PTFE / FEP / PFA Lined Pipe Supplier, Stockist in Gujarat

Galaxy Thermoplast Pvt. Ltd. supplies MS, SS, and CS PTFE-lined pipes, FEP-lined fittings, and PFA-lined valves to process plants across Gujarat. Each pipe pairs a fluoropolymer lining with a metal shell, so the steel carries pressure while the lining maintains corrosive media off the bare metal. Lining thickness usually runs 3mm to 6mm depending on bore size. Plants running hydrochloric acid, sulphuric acid, or caustic soda lines specify this lined pipe because unlined carbon steel or stainless steel corrodes within months under constant exposure. This page covers the full range on offer for Gujarat.

PTFE Line Pipe in Gujarat

FEP Line Elbow in Gujarat

PFA Lined Valves in Gujarat

These Stainless Steel FEP LINED Pipe Fittings also has a high-robustness feature, as they use of Cr has a remarkable impact and raise the strength to a few area. SS 316 PTFE Pipe Fittings offer a excessive amount of Chromium making it one of the most dependable options. SS PTFE LINED Pipes are currently used more in chemical industries. It has a low-maintenance design and tough construction. PTFE/FEP/PFA Lined Pipe is manufactured as per clients specifications and by compulsorily following the national and international quality specification.

Quality Testing & Inspection

All pipes, fittings, and valves are hydrostatically tested at 29.8 kg/cm² and spark tested at 15 kVA before dispatch to ensure that there is no pinhole in the lining. In accordance with our quality system, other tests include intergranular corrosion testing, surface roughness measurement, radiography, fatigue testing, tensile testing, and chemical composition analysis as well as impact testing. Flaring resistance is tested separately on flanged ends, and test records are stored batch-wise and shared with the client on demand.

PTFE, FEP & PFA Lined Products We Supply

Galaxy Thermoplast stocks three lined product families for Gujarat plants, covering straight pipe runs, fittings for direction and bore changes, and valves for flow control. Full dimensional data for each is listed on our technical info page.

PTFE Lined Pipes

PTFE lined pipe is supplied in straight lengths for standard runs, with custom lengths cut where site layout calls for a specific dimension. The lining resists most acids and solvents, keeping pipe walls intact where bare steel would pit.

PTFE-Lined Pipe Fittings

Fittings cover elbows for direction changes, tees and crosses for branch connections, reducers for bore transitions, and stub ends for flanged joints. Lining thickness matches the connecting pipe, so the corrosion barrier operates continuously through bends and junctions.

PTFE Lined Valves

Valve options include ball valves for on-off duty, butterfly valves for large-bore lines, plug valves for slurry service, check valves for backflow prevention, and diaphragm valves for tight shutoff. The lining covers wetted metal parts in every design.

PTFE / FEP / PFA Lined Reducer Specification in Gujarat

Size : 25 NB to 450 NB

Pipe Material : 106 grade B Sch 40 from 25 NB to 150 NB

Flanges Used : ASTM A 105/IS 2062

Hydro Test : at 29.8 Kg/cm2

Spark Test : 15 KVA

PIPE : 1. SEAMLESS CS ASTM A106 GR.B, SCH.-40, 2. ASTM A312 TP 304, SCH.-40

FLANGE : 1. IS 2062 / ASTM A105, 2. ASTM A351 GR. CF8

PTFE / FEP / PFA Line Cross Ready Stock Available for Various Application Industry in Gujarat

PTFE, FEP, and PFA-lined pipe, fittings, and valves go into corrosive-media handling points in process plants, replacing bare metal parts that fail under attack.

Heat exchangers use PTFE-lined elbows and pipe runs where corrosive coolant would pit bare steel within a single operating cycle.
Acid and alkali transfer lines rely on PFA-lined pipe to move hydrochloric acid, sulphuric acid and caustic soda without wall thinning.
Effluent treatment plants install FEP-lined fittings on drain and scrubber lines carrying mixed acidic waste streams.
Reactor charging and discharge lines use PTFE-lined valves to isolate batches without picking up corrosion by-products.
Chemical loading and unloading bays use lined pipe spools at tanker connection points, where spillage exposure runs highest.
Digester and bleaching lines use PFA-lined reducers to step down bore size without losing chemical resistance.

Leading Manufacturers Of PTFE / FEP / PFA Lined Pipe Fittings and Other Products in Gujarat

MS PTFE Lined Cross Supplier in Rajkot
Carbon Steel Lined Cross Supplier in Ahmedabad
CS Line Pipe Supplier in Gujarat
Stainless Steel 316 PTFE Lined Reducer Manufacturer in Vadodara
PTFE Lined Cross in Rajkot
PTFE Line Pipe Price in Gujarat
PTFE Line Valves Price in Gujarat
FEP Line Valves in Ahmedabad
PTFE Lined Valves Supplier in Ahmedabad
PFA Lined Carbon Steel Valves Exporter in Vadodara
Polypropylene Line Tee Stockist in Gujarat
Polypropylene Line Elbow in Gujarat

FEP Line Pipe Fittings Manufacturer in Gujarat
PFA Line Reducer Stockist in Rajkot
Lined Cross Exporter in Ahmedabad
Lined Pipes Distributor in Ahmedabad
PTFE Lining Process in Vadodara
SS 304 Line Tee Manufacturer in Bijapur
CS Line Reducer Distributor in Bijapur
Stainless Steel 304 Lined Tee Stockist in Gujarat
PFA Pipe Fittings Stockist in Ahmedabad
Carbon Steel Line Elbow Exporter in Rajkot
Carbon Steel Line Elbow in Rajkot
PTFE Lined Pipe Fittings Dimensions in Gujarat

Frequently Asked Questions

What is PTFE lining?

PTFE lining is a fluoropolymer lining applied to the inside of a metal pipe, fitting, or valve body. It is sandwiched between the process fluid and metal wall, preventing corrosive media from coming in contact with the underlying metal (steel or stainless steel).

What is the difference between PTFE, FEP, and PFA?

PTFE handles the widest temperature range but is harder to mould into complex shapes. FEP and PFA melt-process more easily, which suits fittings with tighter bends, though both carry a slightly lower maximum service temperature than PTFE.

Which industries use PTFE-lined pipes?

Chemical, pharmaceutical, fertilizer, and textile plants use PTFE-lined pipe wherever a line carries acids, solvents, or caustic solutions that would corrode bare metal.

Can lined fittings handle corrosive chemicals?

Yes. Lined fittings hold up against hydrochloric acid, sulfuric acid, caustic soda, and most industrial solvents at typical process temperatures.

Are custom sizes available?

Yes, custom lengths and bore sizes are available on pipe, fittings, and valves, built to the dimensions on the client’s drawing.
